Providing the bass channel in your surround sound set up, the award-winning ASW608 offers extraordinary power and control for such a compact subwoofer. Even better, it integrates beautifully with the M-1 satellites, creating a coherent, seamless soundscape. Ultra-solid construction and a Class D amplifier deliver maximum bass precision and minimum deformation.
Description Active closed-box subwoofer system
Drive unit 1x ø200mm (8 in) paper/Kevlar® cone long-throw Frequency range -6dB at 23Hz and 25/140Hz adjustable (EQ at A) Frequency response ±3dB 32Hz – 40/140Hz adjustable (EQ at A) Bass Extension -6dB at 23Hz (position A), -6dB at 28Hz (position B), -6dB at 36Hz (position C) Low-pass filter Active 4th-order, variable cut-off frequency Amplifier Power output: 200W Rated power consumption: 40W/ 0.5W standby Impedance: 33k? Signal/noise: >90dB Functions: Volume level – line in, Volume level – speaker in, Low-pass filter frequency, Low-pass filter bypass (line in only), Bass extension, Bass roll-off alignment, Auto sense on/standby, Phase switch Inputs: Line In (RCA Phono), Speaker in (Binding post), 12v trigger (3.5mm jack) Dimensions
Height: 260mm (10.2 in) no feet Width: 260mm (10.2 in) Depth: 330mm (13 in) including grille and controls Weight: 8.85kg (19.5 lb)
