BOWERS AND WILKINS (B&W) ASW608 Active Subwoofer

More Views

BOWERS AND WILKINS (B&W) ASW608 Active Subwoofer
Warranty Period: 2 years Sold as: Single Unit

  As a part of our dealer agreement this product is unavailable for online sale.
  Please CONTACT USCall Now for purchasing options.



Providing the bass channel in your surround sound set up, the award-winning ASW608 offers extraordinary power and control for such a compact subwoofer. Even better, it integrates beautifully with the M-1 satellites, creating a coherent, seamless soundscape. Ultra-solid construction and a Class D amplifier deliver maximum bass precision and minimum deformation.

Description Active closed-box subwoofer system

Drive unit 1x ø200mm (8 in) paper/Kevlar® cone long-throw Frequency range -6dB at 23Hz and 25/140Hz adjustable (EQ at A) Frequency response ±3dB 32Hz – 40/140Hz adjustable (EQ at A) Bass Extension -6dB at 23Hz (position A), -6dB at 28Hz (position B), -6dB at 36Hz (position C) Low-pass filter Active 4th-order, variable cut-off frequency Amplifier Power output: 200W Rated power consumption: 40W/ 0.5W standby Impedance: 33k? Signal/noise: >90dB Functions: Volume level – line in, Volume level – speaker in, Low-pass filter frequency, Low-pass filter bypass (line in only), Bass extension, Bass roll-off alignment, Auto sense on/standby, Phase switch Inputs: Line In (RCA Phono), Speaker in (Binding post), 12v trigger (3.5mm jack) Dimensions
Height: 260mm (10.2 in) no feet Width: 260mm (10.2 in) Depth: 330mm (13 in) including grille and controls Weight: 8.85kg (19.5 lb)

ASW608 Specification Sheet (669 KB)
