ELAC UniFi CC U5 Slim Centre Speaker Black

More Views

ELAC UniFi CC U5 Slim Centre Speaker Black

Regular Price: $895.00

Special Price $829.00

Warranty Period: 5 years Sold as: 1 Unit
Overview

Details

A benchmark to celebrate 90 years of ELAC achievement.

Uni-Fi Slim are the latest additions to the Uni-Fi family of bookshelf, floorstanding and center-channel speakers. The Slim series brings a sophisticated European flair to Uni-Fi, with cabinets that are slimmer, taller and deeper than the originals. And each comes in a high-quality satin painted black or white finish to complement the most elegant décor.

Like the originals, each model in the Slim series is designed by Andrew Jones, and employs the same concentric driver responsible for the award-winning sound of Uni-Fi. Ideal time-domain characteristics result from combining a tweeter and midrange diaphragm within a single voice coil—delivering the most coherent and accurate reproduction across the treble and midrange frequency spectrums. Importantly, Uni-Fi Slim sounds exactly the same as Uni-Fi, employing an identical driver complement, crossover, internal cabinet structure and volume. Only the shape and cabinet are even more refined, featuring a smaller footprint and smooth, satin finish.

ELAC’s chief engineer Andrew Jones explains how Uni-Fi Slim speakers are built on the same foundation: “My goal with the original Uni-Fi series was to create a line of speakers with technology and performance normally reserved for speakers costing significantly more, by going with a 3-way design and employing a new in-house developed concentric driver. With Uni-Fi Slim, design-conscious listeners can enjoy the same outstanding sound along with more elegant proportions ad slim, high-quality cosmetics.”

Uni-Fi Slim can be the basis of an outstanding two-channel system, or used to build an awe-inspiring multi-channel surround-sound system. Add an ELAC subwoofer for the last word in music and movie soundtrack reproduction.



Features

Details

Custom-designed concentric driver

The delicacy of a 1-inch soft-dome tweeter and the harmonic accuracy of a rigid aluminum 4-inch midrange cone come together in a symphony of sonic perfection. Positioning the tweeter concentrically within the midrange voice coil achieves a uniform directivity pattern, for flat frequency response and formidable power handling, along with enhanced imaging for both on- and off-axis listening positions.

Stylish center of for surround-sound.

The perfect complement to a Uni-Fi Slim surround-sound system, the elegant CC U5 Slim paints a seamless center stage for music and film with a slim, 3-way, bass-reflex design that uses the same outstanding concentric driver that makes every model in the Uni-Fi Slim series such a stand-out performer.

Sophisticated crossover

One secret to the great sound of the Uni-Fi Slim series are the high quality, audio-grade components specified in the manufacture of each custom, three-way crossover, the careful design of which is essential to smooth transition between the drivers. The best crossovers are the ones in which the sonic landscape—from lowest fundamentals to highest highs—becomes seamless. This is the sound of Uni-Fi.

Sophisticated aluminum woofer

Through the use of aluminum, resonances that affect the linearity of common paper cones can be placed beyond the driver’s operating frequency range. An extended size magnet with vented pole piece increases power handling, for accurate reproduction of bass frequencies that are clean, clear and powerful.

Custom-designed binding posts

The custom terminals provide flexibility of speaker wire connections and ensure optimal electron transfer from speaker cables to the speaker itself. Details like this make the difference!

Magnetically attached fabric grilles

When the protective grille is removed, hidden magnets beneath the surface of the cabinet keeps the front panel free of attachment holes, for a clean appearance.

Specifications

Details

Speaker type: 3-way, bass reflex
Tweeter: 1 x 1-inch soft dome, concentrically mounted
Midrange: 1 x 4-inch aluminum cone
Woofer: 2 x 5.25-inch aluminum cone
Crossover frequency: 270 / 2,700 Hz
Frequency response: 48 to 25,000 Hz
Sensitivity: 85 dB at 2.83 v/1m
Recommended amplifier power: 40 to 140 wpc
Peak power handling: 140 wpc
Nominal impedance: 4 Ω; minimum 3.4 Ω
Binding posts: 5-way custom
Magnetic shielding: No
Cabinet finishes: Black or white white satin paint finish
Accessories included: Magnetic fabric grille
Height:  7.0 in / 178 mm
Width:  19.61 in / 498 mm
Depth:  11.54 in / 293 mm
