CHORD ELECTRONICS Qutest DAC

More Views

CHORD ELECTRONICS Qutest DAC
Warranty Period: 3 years Sold as: 1 Unit
Overview

Details

Qutest is the latest evolution of Chord Electronics’ most affordable standalone DAC, the multi-award-winning 2Qute, which it directly replaces.
Qutest is uniquely equipped to bring the benefits of Chord Electronics’ acclaimed proprietary hardware and software technology to a wide range of connected devices.

Qutest is our ‘pure’ DAC (it does not contain headphone amplification or rechargeable batteries like some of its range stablemates) and is designed to improve sound quality in the home. It is the latest evolution of our most affordable standalone DAC, the multi-award-winning 2Qute, which it directly replaces. Qutest, which is a What Hi-Fi? Star of CES 2018, is based on our award-winning proprietary FPGA technology developed for the class-leading Hugo 2 DAC/headphone amp, giving it proven class-leading technical and sonic performance.

Perfectly equipped to bring the benefits our digital technology to a wide range of connected devices, it features a galvanically isolated USB-B, optical and coaxial digital input, giving an instant performance upgrade, plus the ability to modernise ageing digital source components. The Qutest chassis is all-new, too. It has significantly greater mass than its predecessor and has been precision-machined from solid aircraft-grade aluminium billet.

The Qutest PCB nestles within a shallow cavity in the solid aluminium chassis, giving the circuit board greater protection within the casework and additional isolation from external vibration compared to previous designs. Qutest offers Hugo 2’s proprietary user-selectable frequency-shaping filters and input selection controls, available via two fascia-mounted spheres, introducing useful flexibility.

It also features RCA analogue outputs for connection to integrated amplifiers, preamps and headphone amps, plus high-resolution dual-data digital inputs for connection to future Chord Electronics products. A further new feature is a user-selectable output voltage available in 1, 2 and 3V RMS outputs for flexible connectivity with a wide range of partnering devices.

Features

Details

  • Chord Custom FPGA DAC
  • 4x Selectable Filters
  • Selectable Output Voltage
  • 768kHz USB Type B Input
  • 192kHz Optical Input
  • USB Galvanic Isolation
  • 2x 384kHz BNC Coax Input
  • 1x Stereo RCA Outputs
  • Supports up to 768kHz PCM
  • Native DSD 512 (8x) Capable
  • Solid Aluminium Chassis

Included Accessories

  • 1.5m 5v 2a Switching Micro USB Power Supply
  • 2m Type A to Type B USB Cable
  • Qutest Owners Overview Manual
  • Raw Silk Drawstring Bag
Specifications

Details

  • Materials: Precision machined aluminium casing with polycarbonate buttons and glass viewing portal.
  • Available in black.
  • Power Supply: 5v 2amp
  • USB Connectivity (input): USB Type B (White): 44.1kHz – 768kHz – 16bit – 32bit 2x
  • BNC Coax (Red): 44.1kHz – 768kHz – 16bit – 32bit
  • Optical (Green): 44.1kHz – 192kHz – 16bit – 24bit
  • Connectivity (output): 1x stereo pair of RCA (Left and Right) PCM support: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 358.8kHz, 384kHz, 717.6kHz, and 768kHz.
  • DSD support: Native playback supported. DSD64 (Single) to DSD512 (Octa-DSD)
  • Variable output: Fixed, but selectable between 3v (blue), 2v (green), and 1v (red) via dual press of ‘Filter’ + ‘Input’ upon startup
  • Driver support: Driverless with Mac OS X and Linux, driver required for Windows OS
  • Digital designer: Rob Watts
  • Mechanical Designer: John Franks

Chipset: Chord Electronics custom coded Xilinx Artix 7 (XC7A15T) FPGA

Tap-length: 49,152

Pulse array: 10 element pulse array design

Frequency response: 20Hz – 20kHz +/- 0.2dB

Output stage: Class A

THD: <0.0001% 1kHz 3v RMS 300Ω

THD and noise at 3v RMS: 117dB at 1kHz 300ohms ‘A’ weighted (reference 2.5v)

Noise 2.6 uV ‘A’ weighted: No measurable noise floor modulation

Channel separation: 138dB at 1kHz 300Ω

Weight: 770g

Dimensions: 41mm (H) x 160mm (W) x 72mm (D)

Boxed Weight: 1500g

Included Accessories

  • 1.5m 5v 2a Switching Micro USB Power Supply
  • 2m Type A to Type B USB Cable
  • Qutest Owners Overview Manual
  • Raw Silk Drawstring Bag
