BOWERS AND WILKINS (B&W) CCM664 In Ceiling Speakers
BOWERS AND WILKINS (B&W) CCM664 In Ceiling Speakers
Warranty Period:5 yearsSold as:One Pair

  As a part of our dealer agreement this product is unavailable for online sale.
  Please CONTACT US for purchasing options.

Overview

Details

The CCM664 features an adjustable, tilt-offset 25mm (1in) soft dome tweeter, and a 150mm (6in) woven glassfibre bass/midrange driver. Quick and easy to install, the speaker also incorporates a three-position EQ switch for a better off-axis response. A cost-effective route to high quality ceiling mount sound. It also features an ultra-narrow bezel and magnetically attached metal grille, both of which can be customized to complement decor.

CCM663

Specifications

Details

Description2-way in-ceiling system
Drive Units1x ø25mm (1in) Nautilus™ swirl loaded aluminium dome tweeter

1x ø150mm (6in) blue Kevlar® cone bass/midrange
Frequency Range (-6dB)45Hz – 35kHz
Recommended Amp Power25 – 130w
Sensitivity SPL (2.83V, 1m)87dB
Impedance Nominal (min)8Ω (4.5Ω)
Frame diameter240mm (9.5in)
Cut-out diameter202mm (8in)
Depth behind surface133mm (5.2in)
Protrusion4mm (0.2 in)
Pre-mount KitC6
Back Box6C
